A4
Connecting the Display
Using the Computer
1. Connect the signal cable. When attached, tighten the thumbscrews to secure
the connection.
2. Connect the power cable with the AC adapter (AC power supply) ②, and
then plug the cable in the outlet. ③(Voltage will be automatically controlled.)
PC
MAC
1
2
Mac adapter
For Apple Macintosh use, a separate plug adapter is needed to
change the 15 pin high density (3 row) D-sub VGA connector
on the supplied cable to a 15 pin 2 row connector.
When
connecting to a
wall concent
When connecting to a PC
AC adapter
3
PC
To Next Page
