LG LMCN125HV User Manual

Here is a brief introduction of the indoor and outdoor units. Please see the information specific to
your indoor unit type.
Product Introduction
4 Multi Air Conditioner
Product Introduction
more than
70 cm
(27.6 inch)
more than
60 cm
(23.6 inch)
more than
30 cm
(11.8 inch)
more than
30 cm
(11.8 inch)
Air Outlet
Air Intake
(side, rear)
Connection pipe
Drain hose
Connecting wire
Control cover
more than 30 cm
(11.8 inch)
Signal receiver
Front panel
Air discharge
ON/OFF button
Power cord
Plasma filter
Air inlet
Air filter
Air inlet
Plasma filter (Optional)
Air filter
Air outlet
Front grille
ON/OFF button
Signal
receiver
Grille tab
Flap
(Horizontal blade)
Louvers
(Vertical blades)
Cabinet
Air Discharge
Air Inlet
Signal receiver
Front Panel
Air outlet vents
Air Inlet
[Standard Type]
[Cealing Concealed Duct Type]
[Artcool Mirror Type]
[Ceiling Cassette Type]
Air outlet vents
Base plate
Connection pipe
Drain hose
Connecting wire
Control cover
Air intake vents
Indoor Unit
Outdoor Unit

LG LMCN125HV Specifications

General

Cooling Capacity	12, 000 BTU/h
Energy Efficiency Ratio (EER)	11.0
Refrigerant	R410A
Power Supply	208-230V/60Hz/1Ph
Operating Temperature (Cooling)	18°C to 43°C
Operating Temperature (Heating)	5-75°F
Dimensions (Indoor Unit)	790 x 250 x 190 mm
Dimensions (Outdoor Unit)	700 x 500 x 240 mm
Weight (Indoor Unit)	19.8 lbs
