ENGLISH
92
SPECIFICATIONS
NOTE

Avoidkeepingafixedimageontheset’s
screenforprolongedperiodsoftime.The
fixedimagemaybecomepermanently
imprintedonthescreen.Useascreensaver
whenpossible.

Theremaybeinterferencerelatingto
resolution,verticalpattern,contrastor
brightnessinPCmode.ChangethePC
modetoanotherresolutionorchangethe
refreshratetoanotherrateoradjustthe
brightnessandcontrastonthemenuuntilthe
pictureisclear.IftherefreshrateofthePC
graphiccardcannotbechanged,changethe
PCgraphiccardorconsultthemanufacturer
ofthePCgraphiccard.

Thesynchronizationinputwaveformfor
HorizontalandVerticalfrequenciesare
separate.

Connectthesignalcablefromthemonitor
outputportofthePCtotheRGB(PC)portof
theMonitorsetorthesignalcablefromthe
HDMIoutputportofthePCtotheHDMI/DVI
INportontheMonitorset.

ConnecttheaudiocablefromthePCtothe
AudioinputontheMonitorset.(Audiocables
arenotincludedwiththeMonitorset).

Ifusingasoundcard,adjustPCsoundas
required.

IfthegraphiccardonthePCdoesnotoutput
analogueanddigitalRGBsimultaneously,
connectonlyoneofeitherRGBorHDMI/DVI
INtodisplaythePCoutputontheMonitor
set.

IfthegraphiccardonthePCdoesoutput
analogueanddigitalRGBsimultaneously,
MonitorsettheMonitorsettoeitherRGBor
HDMI.(TheothermodeissettoPlugand
PlayautomaticallybytheMonitorset.)

DOSmodemaynotworkdependingonthe
videocardifyouuseanHDMItoDVIcable.

IfyouusetoolonganRGB-PCcablethatis
toolong,theremaybeinterferenceonthe
screen.Werecommendusingunder5mof
cable.Thisprovidesthebestpicturequality.
HDMI (DTV) supported mode
Resolution
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
720x480 31.469
31.500
59.940
60.000
720x576 31.250 50.000
1280x720 37.500 50.000
1280x720 44.960
45.000
59.940
60.000
1920x1080 33.720
33.750
59.940
60.000
1920x1080 28.125 50.000
1920x1080 27.000 24.000
1920x1080 33.750 30.000
1920x1080 56.250 50.000
1920x1080 67.430
67.500
59.940
60.000
Component supported mode
Resolution
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
720x480 15.730 59.940
720x480 15.750 60.000
720x576 15.625 50.000
720x480 31.470 59.940
720x480 31.500 60.000
720x576 31.250 50.000
1280x720 44.960 59.940
1280x720 45.000 60.000
1280x720 37.500 50.000
1920x1080 33.720 59.940
1920x1080 33.750 60.000
1920x1080 28.125 50.000
1920x1080 56.250 50.000
1920x1080 67.432 59.940
1920x1080 67.500 60.000
Component port connecting informatio
Componentportsonthe
Monitorset
Y P
B
P
R
Videooutputports
onDVDplayer
Y P
B
P
R
Y B-Y R-Y
Y Cb Cr
Y Pb Pr
