Cooling Capacity Table
ART COOL GALLERY INDOOR UNITS
Table 22: Multi F Art Cool Gallery Indoor Units Cooling Capacity Table.
Model No. /
Nominal Capacity
of Indoor Unit
(Btu/h)
Outdoor Air
Temp.
(°F DB)
Indoor Air Temp. °F DB / °F WB
68 / 57 73 / 61 77 / 64 80 / 67 86 / 72 90 / 75
TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
LMAN097HVP
9,000
14 8.82 5.68 9.37 6.00 9.92 5.81 10.31 5.93 11.01 5.98 11.56 6.09
20 8.82 5.72 9.36 6.04 9.91 5.85 10.31 5.98 11.01 6.03 11.55 6.14
25 8.81 5.77 9.36 6.09 9.90 5.90 10.30 6.02 11.00 6.07 11.54 6.19
30 8.80 5.81 9.35 6.14 9.90 5.94 10.29 6.07 10.99 6.12 11.54 6.23
35 8.80 5.85 9.34 6.18 9.89 5.99 10.28 6.11 10.98 6.17 11.53 6.28
40 8.79 5.90 9.33 6.23 9.88 6.03 10.27 6.16 10.97 6.21 11.52 6.33
45 8.78 5.94 9.33 6.28 9.87 6.08 10.27 6.21 10.96 6.26 11.51 6.38
50 8.78 5.99 9.32 6.32 9.87 6.12 10.26 6.25 10.96 6.30 11.50 6.42
55 8.77 6.03 9.31 6.37 9.86 6.17 10.25 6.30 10.95 6.35 11.49 6.47
60 8.76 6.07 9.31 6.42 9.85 6.21 10.24 6.34 10.94 6.40 11.48 6.52
65 8.76 6.12 9.30 6.46 9.84 6.26 10.24 6.39 10.93 6.44 11.47 6.56
70 8.75 6.16 9.29 6.51 9.84 6.30 10.23 6.43 10.92 6.49 11.47 6.61
75 8.54 6.06 9.08 6.41 9.62 6.21 10.01 6.35 10.71 6.41 11.25 6.54
80 8.33 5.96 8.87 6.31 9.41 6.12 9.80 6.26 10.49 6.33 11.03 6.46
85 8.12 5.85 8.66 6.20 9.20 6.03 9.59 6.17 10.28 6.24 10.82 6.38
90 7.91 5.74 8.45 6.09 8.99 5.93 9.37 6.07 10.06 6.16 10.60 6.30
95 7.68 5.68 8.22 6.04 8.75 5.88 9.00 5.94 9.83 6.12 10.36 6.27
100 7.50 5.52 8.03 5.89 8.57 5.74 8.88 5.85 9.64 5.99 10.17 6.14
105 7.31 5.37 7.84 5.73 8.38 5.60 8.77 5.76 9.45 5.86 9.99 6.01
110 7.12 5.19 7.66 5.55 8.19 5.43 8.58 5.58 9.26 5.69 9.80 5.85
115 6.94 5.03 7.47 5.39 8.01 5.29 8.39 5.44 9.08 5.56 9.61 5.71
118 6.82 5.00 7.36 5.36 7.89 5.26 8.28 5.42 8.96 5.54 9.50 5.70
122 6.79 4.98 7.32 5.35 7.86 5.25 8.24 5.41 8.93 5.53 9.46 5.69
LMAN127HVP
12,000
14 10.98 7.06 11.66 7.46 12.34 7.22 12.84 7.38 13.71 7.44 14.39 7.58
20 10.97 7.12 11.65 7.52 12.33 7.28 12.83 7.43 13.70 7.50 14.38 7.64
25 10.96 7.17 11.64 7.58 12.32 7.34 12.82 7.49 13.69 7.55 14.37 7.70
30 10.95 7.23 11.63 7.64 12.31 7.39 12.81 7.55 13.68 7.61 14.36 7.76
35 10.95 7.28 11.63 7.69 12.31 7.45 12.80 7.61 13.66 7.67 14.34 7.82
40 10.94 7.34 11.62 7.75
12.30 7.51 12.79 7.66 13.65 7.73 14.33 7.87
45 10.93 7.39 11.61 7.81 12.29 7.56 12.78 7.72 13.64 7.79 14.32 7.93
50 10.92 7.45 11.60 7.87 12.28 7.62 12.77 7.78 13.63 7.84 14.31 7.99
55 10.91 7.50 11.59 7.92 12.27 7.67 12.76 7.83 13.62 7.90 14.30 8.05
60 10.90 7.56 11.58 7.98 12.26 7.73 12.75 7.89 13.61 7.96 14.29 8.11
65 10.90 7.61 11.57 8.04 12.25 7.78 12.74 7.95 13.60 8.02 14.28 8.17
70 10.89 7.67 11.56 8.10 12.24 7.84 12.73 8.01 13.59 8.07 14.27 8.23
75 10.63 7.54 11.30 7.97 11.97 7.73 12.46 7.90 13.32 7.97 14.00 8.13
80 10.36 7.41 11.04 7.85 11.71 7.62 12.19 7.79 13.05 7.87 13.73 8.04
85 10.10 7.27 10.77 7.72 11.45 7.50 11.93 7.67 12.79 7.77 13.46 7.94
90 9.84 7.14 10.51 7.58 11.18 7.38 11.67 7.56 12.52 7.66 13.19 7.83
95 9.56 7.06 10.23 7.51 10.89 7.32 11.20 7.39 12.23 7.62 12.89 7.80
100 9.33 6.87 10.00 7.32 10.66 7.15 11.05 7.28 11.99 7.45 12.66 7.64
105 9.10 6.68 9.76 7.13 10.43 6.97 10.91 7.16 11.76 7.29 12.43 7.48
110 8.86 6.46 9.53 6.90 10.20 6.76 10.68 6.95 11.53 7.08 12.19 7.27
115 8.63 6.26 9.30 6.71 9.96 6.58 10.44 6.77 11.30 6.91 11.96 7.11
118 8.49 6.22 9.16 6.67 9.82 6.54 10.30 6.74 11.16 6.89 11.82 7.09
122 8.44 6.20 9.11 6.65 9.78 6.53 10.26 6.73 11.11 6.88 11.78 7.08
TC = Total Capacity (kBtu/h).
SHC: Sensible Heat Capacity (kBtu/h).
Nominal capacity as rated 0 ft. above sea level and a 0 ft. level difference between outdoor and indoor
units. Corresponding refrigerant piping length is accordance with standard length of each outdoor unit.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
The shaded table columns and rows indicate reference data. When operating at this temperature, these
values can be different if the system is not running consistently.
