LG MULTI F MAX Engineering Manual

Dimensions
DUCT (LOW STATIC) INDOOR UNITS
Figure 123:LMDN096HV, LMDN126HV, and LMDN186HV Dimensions.
Note
1. Unit should be installed in compliance with the installation manual in the product box. 2. Unit shall be grounded in accordance with the local regulations or applicable national codes.
30-15/32
ABCD
LMDN096HV LMDN126HV LMDN186HV
27-9/16 28-27/32 25-31/32
25-31/32 35-7/16 36-23/32 33-27/32
(unit: inch)
Name
1
Liquid pipe connection
2
Gas pipe connection
3
Drain pipe connection
4
Power supply connection
5
Air outlet
6
Air intake
Number Descripition
(unit :
inch
)
25/32
D
5
6
2 1 3 4
11-1/2
4-11/16 2-5/8
7-15/32
L1 : 14-13/32 L2 : 22-3/32
3-15/16
3-11/16
27-9/16
7-15/32
25/326-3/32
24-23/32
8-21/32
B
A
C
5-5/161-11/32
Gravity point
L1 : 2-15/16
L2 : 3-1/16
Due to our policy of continuous product innovation, some specications may change without notication.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
92 | DUCT (LOW STATIC)
Multi F and Multi F MAX Indoor Unit Engineering Manual
