6HWWLQJWKH6WDWLF3UHVVXUH&RPSHQVDWLRQ)XQFWLRQ
The Static Pressure Compensation function secures the air flow rate
of the outdoor unit for installations where static pressure has been
applied (Example: When a duct has been added to the outdoor unit
fan discharge.)
Model
ARUN053GSS4, ARUN048GSS4,
ARUN038GSS4
0D[LPXP530
Standard 800
op1 850
op2 850
Set Outdoor Unit PCB DIP Switch No. 5 to ON.
6HOHFWWKHPRGHXVLQJWKHŹDQGŻEXWWRQV
Choose “Func” by pushing the
Ɣ button.
Start the Static Pressure Compensation mode, and save the
VHOHFWHGRSWLRQLQWKH(3520
6HOHFWWKHIXQFWLRQXVLQJWKHŹDQGŻEXWWRQV
Choose “Fn2” by pushing the
Ɣ button.
6HOHFWWKHRSWLRQXVLQJWKHŹDQGŻEXWWRQV
Choose “op1~op2” by pushing the
Ɣ button.
Table 40: 0D[LPXP)DQ530)RU(DFK6WHS
1LJKW/RZ6RXQG)XQFWLRQ
In cooling mode at night when the cooling load is reduced, Night
Low Sound function is used to adjust outdoor unit fan operation to a
ORZHU530UHGXFHVVRXQG
Step
Judgment Time
+RXU
Operation Time
+RXU
op1 8 9
op2 6.5 10.5
op3 5 12
op4 8 9
op5 6.5 10.5
op6 5 12
op7 8 9
op8 6.5 10.5
op9 5 12
op10 Continuous Operation
op11 Continuous Operation
op12 Continuous Operation
op13 6.5 10.5
op14 6.5 10.5
op15 6.5 10.5
Set Outdoor Unit PCB DIP Switch No. 5 to ON.
6HOHFWWKHPRGHXVLQJWKHŹDQGŻEXWWRQV
Choose “Func” by pushing the
Ɣ button.
Start the Night Low Sound function, and save the selected option
LQWKH(3520
6HOHFWWKHIXQFWLRQXVLQJWKHŹDQGŻEXWWRQV
Choose “Fn3” by pushing the Ɣ button.
6HOHFWWKHRSWLRQXVLQJWKHŹDQGŻEXWWRQV
Choose “op1~op15” by pushing the
Ɣ button.
Table 41: Night Low Sound Function Time Settings.
