Owner’s & Installation Manual 7
Remote controller Connection Method
Remote controller Connection Method
1. Check if the cable is properly conneced to CN-REMO port
(CN-AIRCON is used if remote controller is connected with Airconditioner )
2. Connect the cables between the indoor unit and the remote controller.
Connector for the
remote controller side
Connector for the
indoor unit side
P/N:3850A25162L
CN-AIRCON
CN-REMO
CN-AIRCONCN-REMO
* Do not install the cable longer than 50m. (It can cause a communication error.)
While installing the cable, check the connection between the remote controller and the connector.
The connector is not be connected well if extends backwards.
When cable is installated, 3~4 time it turns the cable in Noise filter
After setting the Slide switch on the back of remote controller, push the reset button necessary for
function set.
