Connection Method Between Ventilation Remote Controller and Air conditioner Remote Controller
8 Ventilation Wired Remote Controller
Connection method between ventilation
Connection Method Between Ventilation Remote
Controller and Air conditioner Remote Controller
1. Separate the back cover of the ventilation remote controller
2 Connect the link cable at CN-AIRCON at the back side of the remote controller
3. Separate the back cover of the air conditioner remote controller
P/N:3850A25162L
CN-AIRCON
CN-REMO
< Airconditioner remote controller >
< Ventilation remote controller >
4. Connect the link cable at CN-VENTIL at the back side of the remote controller
Ventilaton remote controller can be installed along with air conditioner remote controller. But connect ventilation
wired remote controller and air conditioner wired remote controller only when its necessary.
