LG WFT15D81E(H)P User Manual

2
SAFETY PRECAUTION!
IMPROTANT SAFERY NOTICE!
DISASSEMBLE POWER CORD BEFORE SERVICING
RECONNECT ALL GROUNDING DEVICES
This service information is intended for individuals
possessing adequate backgrounds of electrical,
electronic and mechanical experience.
Any attempt to repair this appliance may result in
personal injury or property damage.
The manufacturer or seller can not be responsible for the
interpretation of this information, nor can it assume any
liability in connection with its use.
1. Specifications ................................................................................................................................................................ 3
2. Installation Instructions .................................................................................................................................................. 4
3. Operating Instructions
3-1. Identification of Parts ........................................................................................................................................... 10
3-2. Before Starting to Wash ....................................................................................................................................... 11
3-3. Function of Each Button ....................................................................................................................................... 16
3-4. Washing Programs .............................................................................................................................................. 18
3-5. Other Functions ................................................................................................................................................... 20
3-6. Care and Maintenance ......................................................................................................................................... 28
4. Service Information
4-1. Schematic Diagram .............................................................................................................................................. 29
4-2. Wiring Diagram .................................................................................................................................................... 30
4-3. Program Time Chart ............................................................................................................................................ 31
4-4. Adjustment ........................................................................................................................................................... 33
4-5. Disassembly Instruction ....................................................................................................................................... 34
4-6. Test Running without water ................................................................................................................................. 37
4-7. Trouble Shooting against Common Washing Problems ...................................................................................... 38
4-8. Trouble Shooting according to Error Message .................................................................................................... 39
4-9. How to Diagnose and Repair by Symptom .......................................................................................................... 41
5. Exploded View ............................................................................................................................................................ 51
6. Replacement Part List ................................................................................................................................................. 55
CONTENTS

LG WFT15D81E(H)P Specifications

General

POWER SOURSE	Refer to rating label on the back of Washer
AUTO POWER OFF	Applied
INPUT	Refer to rating label on the back of Washer
CAPA CITY	Refer to rating label on the back of Washer
SPIN SPEED	220 ~240 V / 50Hz : 680 50 110~127 V / 60Hz : 680 50 220 V / 60Hz : 730 50
INNER TUB	Stainless
LINT FILTER	Single
SOFTENER DISPENSER	Applied
DETERGENT DISPENSER	Applied
BLEACH INILET	Applied
ADDITIVES DISPENSER	Applied
INLET WATER PRESSURE	0.3kgf/cm2 ~ 8kgf/cm2
WATER LEVEL	9 Stages
PROGRAM	Fuzzy, Hand Wash, Heavy, Delicate, Wool, Eco Save, Wash Only, Quick Wash, Rinse / Spin, Spin Only
RESERVATION	Available for 3~ 48 Hr
UNBALANCE SWITCH	B.P Sensor
LID INTERLOCK SWITCH	Magnet Sensor
CHILD LOCK	Applied

Weight and Dimensions

DIM.	Refer to rating lavel on the back of Washer
WEIGHT	Refer to rating lavel on the back of Washer
