LG WFT15D81E(H)P User Manual

39
4-8. TROUBLE SHOOTING METHODS ACCORIDNG TO ERROR MESSAGE
For more detailed information for trouble shooting refer to page 44 to 53.
ERROR
WATER
SUPPLY &
INLET V/V
DRAINAGE
UNBALANCE
OVER
FLOODING
ERROR
WATER LEVEL
dose nto rise to
the set level in 40
minutes.
Water is not
completely
drained in 10
minutes.
Laundry
unbalance during
spin.
In the second QC
Mode the
following message
is displayed.
Water faucet is closed?
Water supply is interrupted.
Inlet V/V is clogged with
dirts.
Connector has bad contact
to the inlet valve.
Red(RD), White(WH),
Blue(BL), Yellow(YL) 3 pin
connector has bad contact to
the P.W.B ASM.
Is the drain hose located
properly?
Drain hose is not lowered.
Drain hose is folded or
clogged due to freeze or
dirts.
Bad Drain Motor part or
Yellow(YL) 3 pin connector
to the P.W.B ASM has bad
connection.
Laundry in the INNER TUB
is filled unevenly.
Washer is tilted.
S.F S/W is too closed to the
washing tub, or has bad
contact.
Is the CONNECTOR of Ball
pressure sensor
disconnected or badly
touched?
Check INLET valve
Open water faucet.
Wait until water supply is
resumed.
Clean or replace filter.
Correct the connector
contact.
Same as above.
Hung up drain hose at
0.9~1.3m high.
Unclog the drain hose.
Replace Drain Motor or
correct the connector
contact.
Try to fill laundry uniformly
in the inner tub.
Adjust the leg.
Check and replace S.F S/W.
Check B.P SENSOR
CONNECTOR or replace
B.P sensor
ERROR DECISION
BASIS
CAUSE FOR ERROR
OCCURRENCE
REMEDY

LG WFT15D81E(H)P Specifications

General

POWER SOURSE	Refer to rating label on the back of Washer
AUTO POWER OFF	Applied
INPUT	Refer to rating label on the back of Washer
CAPA CITY	Refer to rating label on the back of Washer
SPIN SPEED	220 ~240 V / 50Hz : 680 50 110~127 V / 60Hz : 680 50 220 V / 60Hz : 730 50
INNER TUB	Stainless
LINT FILTER	Single
SOFTENER DISPENSER	Applied
DETERGENT DISPENSER	Applied
BLEACH INILET	Applied
ADDITIVES DISPENSER	Applied
INLET WATER PRESSURE	0.3kgf/cm2 ~ 8kgf/cm2
WATER LEVEL	9 Stages
PROGRAM	Fuzzy, Hand Wash, Heavy, Delicate, Wool, Eco Save, Wash Only, Quick Wash, Rinse / Spin, Spin Only
RESERVATION	Available for 3~ 48 Hr
UNBALANCE SWITCH	B.P Sensor
LID INTERLOCK SWITCH	Magnet Sensor
CHILD LOCK	Applied

Weight and Dimensions

DIM.	Refer to rating lavel on the back of Washer
WEIGHT	Refer to rating lavel on the back of Washer
