LG WFT15D81E(H)P User Manual

43
4) Water doesn’t come into the wash tub.
Where, what & how to check?
Result of Check
Possible Cause
How to repair & settle
Inlet Valve
1. If water doesn’t come though the inlet
valve works(electric sound occurs)
1) Check whether water mains is cut.
2) Check whether tabs are turned on.
3) HOT & COLD tab are opposite
connected.
4) Wrongly select Water Temperature
option.
5) If there are no problems in the above,
check the inlet valve filters after
disconnecting the water supply hoses.
6) If there are no problems in the above a
diaphragm hole in the valve is blocked
by foreign substance or the plunger in it
is locked.
2. If the inlet valve doesn't work(there is no
electric sound)during filling cycle.
1) Check whether it’s connectors are taken
off or they have poor connection.
2) Check resistance of the inlet valve.
Water mains cut.
Dont tumed on.
Connected opposite.
Selected opposite.
Filters blocked by
foreign substance.
A connector is taken
off.
∞Ω
Mains cut.
Mistake of use.
Wrong installation.
Mistake of use.
Don’t clean.
Defect of the inlet valve.
Defect of contact.
Coil is open
Explain.
Turn on the tap.
Correct their locations and
turn on the tap.
Explain how to use.
Clean them by brush and
explain cleaning regulary
them.
Change the inlet valve.
Reconnect it or remove
the causes to make poor
connection.
Change the inlet valve.
3) Reset During operation
Where, what & how to check?
Result of Check
Possible Cause
How to repair & settle
Drain Motor
1. Operate washer setting spin only, then
press the START/PAUSE button when
the wash motor starts to work and then
press the START/PAUSE button again
in order for the drain motor to work
intermittently.
Controller
1. If mains voltage and the drain motor
have no defects a defect of the controller
is highly possible.
Reset happens after
the drain motor
works.
Defect of the drain motor
(A noise generated when
the internal relay works.)
Change the drain motor
Change the controller.

LG WFT15D81E(H)P Specifications

General

POWER SOURSE	Refer to rating label on the back of Washer
AUTO POWER OFF	Applied
INPUT	Refer to rating label on the back of Washer
CAPA CITY	Refer to rating label on the back of Washer
SPIN SPEED	220 ~240 V / 50Hz : 680 50 110~127 V / 60Hz : 680 50 220 V / 60Hz : 730 50
INNER TUB	Stainless
LINT FILTER	Single
SOFTENER DISPENSER	Applied
DETERGENT DISPENSER	Applied
BLEACH INILET	Applied
ADDITIVES DISPENSER	Applied
INLET WATER PRESSURE	0.3kgf/cm2 ~ 8kgf/cm2
WATER LEVEL	9 Stages
PROGRAM	Fuzzy, Hand Wash, Heavy, Delicate, Wool, Eco Save, Wash Only, Quick Wash, Rinse / Spin, Spin Only
RESERVATION	Available for 3~ 48 Hr
UNBALANCE SWITCH	B.P Sensor
LID INTERLOCK SWITCH	Magnet Sensor
CHILD LOCK	Applied

Weight and Dimensions

DIM.	Refer to rating lavel on the back of Washer
WEIGHT	Refer to rating lavel on the back of Washer
