46
7) Water does not drain.
Where, what & how to check?
Result of Check
Possible Cause
How to repair & settle
Drain Pump
1. Check whether there is drain pump
working sound.
2. Check resistance between terminals if
there is no working sound of the drain
pump.
3. Check connection parts of the leads if
there is no working sound and its
resistance is normal.
Drain Hose
1. Check whether the drain hose is put in a
narrow space and kinked.
2. Check whether the drain hose is
blocked by foreign objects. It may
happen in case of the hose is a little
kinked.
There is pump
working sound.
∞Ω
Defect in connection
part.
Connection part has
no defects.
Kinked.
Blocked.
Drain pump is blocked by
foreign objects.
It’s coil is open.
Defect in connection part.
Defect of the controller.
Defect of installation.
Blocked hose.
Disassemble the drain
pump cap and remove the
foreign objects in the pump
casing.
Change the drain pump.
Repair defected connection.
Change the controller.
Reinstall so that it should
not be kinked.
Remove the objects and
reinstall so that it can’t
be kinked.
6) Pulsator doesn’t rotate normally.
Where, what & how to check?
Result of Check
Possible Cause
How to repair & settle
4. Pulsator weakly rotates.
1) Check voltage at the power outlet where
the washer is plugged into.
2) Check capacitance of the capacitor.
Less than 85% of
rating.
Indicating needle
rises and immediately
indicates ∞
The needle is
stopped after it is
raised.
The needle doesn’t
move.
Lower voltage.
Capacitor is normal.
Lack of capacitance of the
capacitor.
Capacitor is fully
discharged.
Explain the causes and a
transfomer should be used if
necessary.
Change the capacitor.
Change the capacitor.

LG WFT15D81E(H)P Specifications

General

POWER SOURSE	Refer to rating label on the back of Washer
AUTO POWER OFF	Applied
INPUT	Refer to rating label on the back of Washer
CAPA CITY	Refer to rating label on the back of Washer
SPIN SPEED	220 ~240 V / 50Hz : 680 50 110~127 V / 60Hz : 680 50 220 V / 60Hz : 730 50
INNER TUB	Stainless
LINT FILTER	Single
SOFTENER DISPENSER	Applied
DETERGENT DISPENSER	Applied
BLEACH INILET	Applied
ADDITIVES DISPENSER	Applied
INLET WATER PRESSURE	0.3kgf/cm2 ~ 8kgf/cm2
WATER LEVEL	9 Stages
PROGRAM	Fuzzy, Hand Wash, Heavy, Delicate, Wool, Eco Save, Wash Only, Quick Wash, Rinse / Spin, Spin Only
RESERVATION	Available for 3~ 48 Hr
UNBALANCE SWITCH	B.P Sensor
LID INTERLOCK SWITCH	Magnet Sensor
CHILD LOCK	Applied

Weight and Dimensions

DIM.	Refer to rating lavel on the back of Washer
WEIGHT	Refer to rating lavel on the back of Washer
