8) Water drains thought it is not the time of drain.
Where, what & how to check?
Result of Check
Possible Cause
How to repair & settle
PV Case
1. If water drains though the drain motor is
normally returned, check whether PV
asm is blocked by foreign objects or the
bellows in the PV asm is deformed.
Controller
1. Check whether the drain motor or the
drain pump works immediately after
power is turned on.
Blocked.
Bellows deformed.
Works.
Defect of PV Bellows.
Defect of the controller
(Triac defect)
Remove the objects in the
PV asm.
Change the PV bellows.
(The bellows may swell up if
it contact petroleum or
petrochemical substance
because it is made of rubber)
Change the controller.
9) Drain error happens while water drains normally.
Where, what & how to check?
Result of Check
Possible Cause
How to repair & settle
Ball Pressure Sensor
(Pressure Switch)
1. Check generation frequency of the Ball
Pressure Sensor (Pressure Switch)
without water.
Less than
26.3 kHz
26.3~27.1 kHz
Defect of the Ball Pressure
Sensor(Pressure Switch).
Defect of the controller.
Change the Ball Pressure
Sensor (Pressure Swtich)
Change the controller.
10) Spin extraction is not proceeded.
Where, what & how to check?
Result of Check
Possible Cause
How to repair & settle
Motor
1. In the case that the wash motor does
not spin during spin extraction;
1) Check there is motor working sound,or
There is motor
working sound.
Defect of the capacitor or
Mechanically locked.
Change the capacitor after
checking defect of
capacitor. check whether
the washing clutch or the
washing tub is blocked if the
motor rotates after removing
the V-belt. Check whether
the motor is locked if the
motor does not rotates even
though the V-belt being
removed.

LG WFT15D81E(H)P Specifications

General

POWER SOURSE	Refer to rating label on the back of Washer
AUTO POWER OFF	Applied
INPUT	Refer to rating label on the back of Washer
CAPA CITY	Refer to rating label on the back of Washer
SPIN SPEED	220 ~240 V / 50Hz : 680 50 110~127 V / 60Hz : 680 50 220 V / 60Hz : 730 50
INNER TUB	Stainless
LINT FILTER	Single
SOFTENER DISPENSER	Applied
DETERGENT DISPENSER	Applied
BLEACH INILET	Applied
ADDITIVES DISPENSER	Applied
INLET WATER PRESSURE	0.3kgf/cm2 ~ 8kgf/cm2
WATER LEVEL	9 Stages
PROGRAM	Fuzzy, Hand Wash, Heavy, Delicate, Wool, Eco Save, Wash Only, Quick Wash, Rinse / Spin, Spin Only
RESERVATION	Available for 3~ 48 Hr
UNBALANCE SWITCH	B.P Sensor
LID INTERLOCK SWITCH	Magnet Sensor
CHILD LOCK	Applied

Weight and Dimensions

DIM.	Refer to rating lavel on the back of Washer
WEIGHT	Refer to rating lavel on the back of Washer
