LG WT1201C Series Service Manual

16
3-3. FUNCTION OF EACH BUTTON
· Select to select Wash
Temperature.
· Pressing the button allows
The selection of TAP COLD
▶COLD ▶ECO WARM
▶WARM▶HOT respectively.
Default setting is Warm.
Wash / Temp.
Note
The time shown on the display is the estimated cycle time. If the sensors and microprocessor elect to
make changes during the cycle, the display will be adjusted accordingly.
Load Sensing
·It operates in all cycles.
· During being detected by the sensor, the
LOADSENSING LED flashes.
·It automatically sensing the size of the load.
· During this step, the washing machine selects
an optimized washing algorithm.
Soil Level
· Allows a selection to be make for the
strength of the wash action.
· Power option selections light up in
sequence as follows Normal ▶ Heavy
▶ Light ▶ Normal as the button is
pushed.
This can be selected for any program.
· Adjustment can be made while
washing.
· Default SOIL LEVEL is Normal.
Spin Speed
· Spin speed
can be
selected from
No Spin to
Extra high.
Default is
High.

LG WT1201C Series Specifications

General

Style	Top-Loading
Color	Chrome
Washer Capacity	4.3 cu ft
Dryer Capactity	-
Max Spin Speed	1100 RPM
Spin Speeds	Low
Spin Class	C
Number of Cycles	8
Cycle Selections	Mixed 40°
Wash	Quick Wash
Options	ColdMotion technology
Hours	Extra Power / Boost Option
Noise level
Temperature Selections	Cold
Energy Class	-
Annual Energy Consumption	-
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120 V
Frequency	-
Current	10 A

Weight and Dimensions

Depth	28 3/8 in
Height	40 5/32 in
Width	27 in
Net Weight	134.2 lbs
