LG WT1201C Series Service Manual

36
UNBALANCE ERROR
Yes
Is UE displayed?
Put laundry evenly
In the DRUM
assembly
No
Does the laundry lean toward
one side, not evenly put in the
DRUM assembly?
Is the washing machine
installed at an angle?
Yes
Yes
Does the inlet valve work
when the power is not
applied?
Replace the INLET VALVE
ASSEMBLY
No
Adjust the height of
washing machine
to be kept
horizontally
Yes
If the inlet valve
works
continuously when
the power is
applied, replace
the MAIN PCB
ASSEMBLY
OVER FLOW ERROR
Yes
Is FE displayed?
Check the AIR
CHAMBER and the
tube (clogged).
Yes
When you enter the service
mode, is the water level
frequency over 21.0 kHz?
No

LG WT1201C Series Specifications

General

Style	Top-Loading
Color	Chrome
Washer Capacity	4.3 cu ft
Dryer Capactity	-
Max Spin Speed	1100 RPM
Spin Speeds	Low
Spin Class	C
Number of Cycles	8
Cycle Selections	Mixed 40°
Wash	Quick Wash
Options	ColdMotion technology
Hours	Extra Power / Boost Option
Noise level
Temperature Selections	Cold
Energy Class	-
Annual Energy Consumption	-
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120 V
Frequency	-
Current	10 A

Weight and Dimensions

Depth	28 3/8 in
Height	40 5/32 in
Width	27 in
Net Weight	134.2 lbs
