LG WT1201C Series Service Manual

5
26.8″
(68.0 cm)
4.7″
(12.0 cm)
54.33″
(138.0 cm)
(with lid
open)
27.4″
(69.6 cm)
0.8″
(2.0 cm)
0.8″
(2.0 cm)
40.16″
(102.0 cm)
6
75
Confirming level
• Place the washer in original position,
confirming the level.
Horizontal setting
• If the washer is not level, adjust the
leveling feet. Turn clockwise to raise,
counterclockwise to lower.
Distance between the drain hose
and the wall
• Distance between the drain hose and
the wall should be more than 4 inches
(10 cm,) and the distance between any
other part and the wall should be more
than 1 inches (2.5 cm.)
Do not install the washer in the following places.
• Where the washer is exposed to direct sunlight.
• Near a heater or heating appliance.
• Where the washer is exposed to freezing temperatures.
• In damp environments such as bathrooms or harmful environments.
Lower
Raise
side to side
front to back

LG WT1201C Series Specifications

General

Style	Top-Loading
Color	Chrome
Washer Capacity	4.3 cu ft
Dryer Capactity	-
Max Spin Speed	1100 RPM
Spin Speeds	Low
Spin Class	C
Number of Cycles	8
Cycle Selections	Mixed 40°
Wash	Quick Wash
Options	ColdMotion technology
Hours	Extra Power / Boost Option
Noise level
Temperature Selections	Cold
Energy Class	-
Annual Energy Consumption	-
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120 V
Frequency	-
Current	10 A

Weight and Dimensions

Depth	28 3/8 in
Height	40 5/32 in
Width	27 in
Net Weight	134.2 lbs
