Appendix 3 Installation Drawing 55
Liebert.CRV Series Air Conditioner User Manual
Appendix 3 Installation Drawing
2000
Front view
600
7
5
1
1
7
5
Figure 5 Dimensions of the air conditioner (unit: mm)
1
2
4
5
1
2
4
5
Figure 6 Front and back service area (unit: mm)
