Digit Description
Digit 14 = Air filter
8 = MERV 8, 2-in. Pleated
9 = MERV 11, 2-in. Pleated
Digit 15 Coil, Valve Type & Pressure Rating
1
0 = Air-Cooled only
B = Dual Cool/Air-Cooled, 150 PSIG CW MBV
E = Dual Cool/Air-Cooled, 400 PSIG CW MBV
1 = W/G, 2-way 150 PSIG Condenser MBV
2 = W/G, 2-way 400 PSIG Condenser MBV
7 = W/G, 3-way 150 PSIG Condenser MBV
8 = W/G, 3-way 400 PSIG Condenser MBV
Digit 16 = Enclosure Options
1 = Standard Enclosure
C = Double-skin panels
Digit 17 = High-voltage Options
M = Locking Disconnect
P = Locking Disconnect with condensate pump
Digit 18 = Low-voltage Option Packages
0 = None
L = Low Voltage Terminal Package (LVTP)
H = Reheat and Humidifier (R/H) Lockout
R = Remote Humidifier Contact (RHC)
C = LVTP and R/H Lockout
D = LVTP and RHC
E = LVTP and R/H Lockout and RHC
F = RHC and R/H Lockout
Digit 19 = Monitoring Cards
0 = No Card, IntelliSlot™ only
U = 1 Liebert IntelliSlot™ IS-UNITY-DP Card
C = 1 Liebert IntelliSlot IS-485EXI Card
6 = 1 IS-Unity-DP and IS-485EXI Card
7 = 2 Liebert IntelliSlot IS-UNITY-DP Cards
Digit 20 = Sensors
0 = None
S = Smoke Sensor
H = High-temperature Sensor
C = Compressor Overload Sensor
F = Smoke and High-temperature Sensors
A = Smoke and Compressor Overload Sensors
D = High-temperature and Compressor Overload Sensors
K = Smoke, High-temperature and Compressor Overload Sensors
Digit 21 = Packaging
P = Domestic
C = Wood Crate Export
Digit 22 = Factory Configuration code
A = No SFA’s (Any Alpha letter except S)
S = SFA
Table B.2 PDX Model-number Digit Definitions (continued)
Vertiv | Liebert® PDX™ and PCW™ Installer/User Guide | 101
