3.1 Planning Dimensions
The unit, floor stand, and plenum dimensions are described in the submittal documents included in the
Submittal Drawings on page106.
The following table lists the relevant documents by number and title.
Document Number Title
Downflow Units
DPN002936 Cabinet Dimensional Data, Downflow Models
DPN002944 Cabinet Dimensional Data, Downflow Floor Level Discharge Models
Upflow Units
DPN002937 Cabinet Dimensional Data, Upflow Models
DPN002971 Cabinet Dimensional Data, Upflow Rear Return Models
Floor Stands
DPN002970 Floorstand & Floor Planning Dimensional Data, Downflow Models
DPN002971 Floorstand Dimensional Data, Upflow Rear Return Models
Plenums
DPN002981 Plenum Dimensional Data, Upflow Discharge Grille
DPN003697 Plenum Dimensional Data, Upflow Discharge w/ Duct Collar
DPN003447 Plenum Dimensional Data, Top Discharge Upflow Units
DPN003610 Downflow Plenum Dimensional Data
DPN002936 Duct-flange Dimensions, Downflow models, Field-supplied ductwork
Table 3.1 Dimension Planning Drawings
3.2 Considerations for Air Distribution
Depending on the intake/discharge configuration of the unit, consider the following when preparing for
installation:
When installing a downflow unit with raised-floor discharge:
• Verify that the raised floor is properly sized for the unit’s airflow and the room is free of airflow
restrictions.
• Perforated floor tiles in the raised floor should ensure minimal pressure loss.
• The raised floor must provide a minimum of 7-1/2in. (191mm) of clearance.
• Ensure that there is adequate clearance above the unit for return air. See DPN002936 in the
Submittal Drawings on page106.
When installing a downflow units with floor-level discharge:
• Provide several feet of clearance for air discharge of the unit.
• Ensure that there is adequate clearance above the unit for return air. See DPN002944 in the
Submittal Drawings on page106.
When installing upflow units
• Provide several feet of clearance for intake and discharge of the unit or for supply and return
ducting.
• Provide clearance for service access. See DPN002937 in the Submittal Drawings on page106.
Vertiv | Liebert® PDX™ and PCW™ Installer/User Guide | 18
