2.1 Liebert PDX Model-number Nomenclature
The tables below describe each digit of the 25-digitconfigurationnumber. The 14-digit model number
consists of the first 10 digits and last 4 digits of the configuration number.
For the full description of configuration and model number refer to Liebert PDX Model-number Detail on
page99.
Model Number Digits 1 to 10 Model Details
ModelNumber Digits
11to14
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25
P X 0 2 9 D A 1 A D H H 2 8 0 1 P L U F P A # # #
Table 2.1 PDX 25-digit Configuration Number
Digits 1 and 2 = Unit Family
Digit 15 Coil, Valve Type & Pressure Rating
1
Digit 3, 4, 5 = Nominal Cooling Capacity, kW Digit 16 = Enclosure Options
Digit 6 = Air Direction and Discharge Digit 17 = High-voltage Options
Digit 7 = System Type Digit 18 = Low-voltage Option Packages
Digit 8 = Fan Type Digit 19 = Monitoring Cards
Digit 9 = Power Supply Digit 20 = Sensors
Digit 10 = Compressor & Valve (R-410A) Digit 21 = Packaging
Digit 11 = Humidifier Digit 22 = Factory Configuration code
Digit 12 = Display Digit 23-25 = Factory Configuration Number
Digit 13 = Reheat N/A
Digit 14 = Air filter N/A
1. High-pressure MBV also results in high-pressure Econ-O-Coilvalve.
Table 2.2 PDX Model-number Digit Summary
