4.3.3 Moving the Unit with Piano Jacks
1. With the unit raised by a forklift, pallet jack or rigging according to the previous instructions,
position a piano jack on either side of the elevated unit, see Figure 4.7 below, then lower the
unit to a height suitable for the piano jacks.
Figure 4.7 Lower unit to piano jacks
2. Place protective padding between the unit and the piano jacks and straps, then secure the
unit to the piano jacks with the straps as shown in Figure 4.8 below.
Figure 4.8 Unit strapped to piano jacks
Item Description
2 Protective padding between piano jacks and straps.
3 Second piano jack on opposite side.
Vertiv | Liebert® PDX™ and PCW™ Installer/User Guide | 27
