3. Referring to Figure 4.6 below:
• Use spreader bars or an equivalent device to protect the unit from crushing when it is
lifted with the slings. Ensure that the unit’s panels, if the bag is removed, are protected
from the slings.
NOTE: If rigging will be used to move the unit closer to the site for installation, place one or two
horizontal straps around the unit at mid-height.
• Lift the unit off the skid to a point where the weight of the unit is not resting on the skid,
and remove the skid from under the unit.
4. To move the unit with piano jacks, keep the unit elevated, and refer to Moving the Unit with
Piano Jacks on the facing page.
Figure 4.6 Remove the unit from the skid with rigging
Item Description
1 Use spreader bars and protect unit from slings.
2 Lift unit so that weight is not on skid, and remove the skid.
3 Horizontal strap location, at mid-height of unit.
Vertiv | Liebert® PDX™ and PCW™ Installer/User Guide | 26
