Block the wheels
Screw off the wheel nuts
620
620
Screw off the bolts and remove the spare
tire. Then take off the spare tire from the
vehicle.
Put the spare tire with the outside up into
the storage compartment when storing
the spare tire. And then fix it, reverse to
the above removal procedures to prevent
the tire from being thrown forward in case
of an emergency brake or collision.
Set a baffle plate under the tire in the
diagonal direction of the replaced
tire when using a jack, to avoid
vehicle slide.
When blocking the wheel, put the baffle
plate in front of the front wheel or behind
the rear wheel.
Screw off all wheel nuts of the flat tires.
Screw off the wheel nuts before lifting the
vehicle.
Turn the wheel nuts counter-clockwise and
screw them off. To get a maximum torque, put
the wrench into the nut according to the fig.
above and make the wrench knob at right.
Hold the end of wrench knob and pull it up.
Be noted that the wrench should not slip
out from the nut. Do not remove the nut,
only screw it off for one and a half turns.
Jack alignment
Lifting the vehicle
Put the jack at the correct jacking
point according to this fig.
Make sure that the jack is put on flat
and firm ground.
Lift the vehicle to a height at which
the spare tire can be installed.
Before lifting the vehicle, insert the jack
knob into the jack (loose contact), and
then turn it clockwise. When the jack
contacts the vehicle and starts rising,
recheck if it is at the correct position.
Warning
Personnel should not be under the
vehicle supported by a jack only.
