Once the AutoTest has started, the results
of the capacitors that are connected and
disconnected are shown:
Leakage current (mA)
Capacitive Reactive Power
(kvarC or MvarC)
Capacitive Power % of each capacitor
relative to the total estimated value.
The icon blinks during the AutoTest.
A long press (> 3 s) of the key cancels the AutoTest.
At the end of the AutoTest, the unit automatically returns to the Individual Test screen.
Individual Test Parameters
Leakage current (mA)
Capacitive Reactive Power
(kvarC or MvarC)
Capacitive Power % of each capacitor
relative to the total estimated value.
Switches between the various
capacitors.
A long press (> 3 s) of the key connects the capacitor that is being displayed, taking into
account the programmed connection and reconnection times.
A long press (> 3 s) of the key disconnects the capacitor that is being displayed, taking into
account the programmed connection and reconnection times.
55
