Cosine φ test Parameters
Display screen of the:
Cos φ (2U.1C and 3U.1C connection)
L1 Cos φ (3U.3C connection)
L2 Cos φ (3U.3C connection)
L3 Cos φ (3U.3C connection)
Cos φ III(3U.3C connection)
L: Inductive / C: capacitive
+: consumed / -: generated
Current THD Test Parameters
Display screen of the:
Current THD (2U.1C and 3U.1C connection)
L1 Current THD (3U.3C connection)
L2 Current THD (3U.3C connection)
L3 Current THD (3U.3C connection)
Power III Test Parameters
Display screen of the:
Active Power III(kW or MW)
Inductive Reactive Power III
(kvarL or MvarL)
Capacitive Reactive Power III
(kvarC or MvarC)
Apparent Power III (kVA or MVA)
56
Controller MASTER control VAR FAST
Instruction Manual
