Life EVOS XL Core User Manual

22
Appendix B: Specifications
Model
EVOS
®
XL Core Imaging System
(Cat. no. AMEX1000)
Optics
Infinity-corrected optical system; RMS-threaded objectives with 45-mm parfocal
distance
Objectives
4×, 10×, 20×, 40×; plan LWD phase, infinity
Optional 2× and 100× (no phase) available
Objective turret
4-position; manual control
Illumination
LED (50,000+ hour life); adjustable intensity
Contrast
methods
Transmitted light (brightfield and phase contrast)
Condenser
3-position turret for brightfield and phase contrast; 60 mm working distance
Stage
Fixed stage (optional mechanical stage available)
Focus
mechanism
Coaxial focus knobs with tension control
Coarse focus: 38 mm/rev
Fine focus: 0.2 mm/rev, precision 0.002 mm
LCD display
12.1-inch color, 1024 × 768 pixels; adjustable tilt
Camera
1/2-inch, 2048 × 1536, 3.1 Megapixels, COLOR
acquisition
Embedded operating system with imaging software for image capture and save via
mouse or front-mounted manual buttons
Captured
images
24 bits/pixel, full color TIFF, JPG or BMP
2048 × 1536 pixels
Output ports
2 USB 2.0 ports
Power supply
AC Adapter; Input 100-240V, 47-63Hz; 0.58A max; Output 12 VDC/2.0A 24W max
Dimensions
Operating height: 53.3 cm (21.0 in)
Storage/transport height: 36.8 cm (14.5 in)
Depth: 40.6 cm (16.0 in)
Width: 31.8 cm (12.5 in)
Weight
9.1 kg (20.1 lbs)
