LifeSpan C2 User Manual

C2 UPRIGHT ASSEMBLY
Step 1: Front Base Assembly
Parts Required
Main Frame
Front Base
Hardware Required
Part # Size Description Quantity
A-1 M10 * 90 Dome Head Allen Screw 2
C-1 M10 Curved Washer 2
1. Locate the hardware bag for Step 1.
2. Place the front base over the frame aligning
the holes in the base with the threaded holes
in the frame.
3. Insert the two 6 mm dome head screws with
bent washers into the holes in the front base
and tighten screws.
Step 2: Rear Base / Seat Assembly
Parts Required
Rear Base
Seat
Hardware Required
Part # Size Description Quantity
A-1 M10 * 90 Dome Head Allen Screw 2
C-1 M10 Curved Washer 2
Rear Base
1. Locate the hardware bag for Step 2.
2. Place the rear base over the frame aligning the
holes in the base with the threaded holes in
the frame.
3. Insert the two 6 mm dome head screws with
bent washers into the holes in the front base
and tighten screws.
Seat
1. Push the seat down all the way onto the seat post spindle.
2. Making sure that the seat points straight forward and is level to the ground, tighten
the two 14 mm nuts on each side of the seat clamp.
15
