Step 5: Handlebar Assembly
Parts Required
Handlebar
Hardware Required
Part # Size Description Quantity
A-4 M8*16 Dome Head Allen Screw 4
C-4 M8 Flat Washer 4
1. Place the handlebars over the frame and connect the wiring harness for the contact
heart rate.
2. Tuck excess wiring and connectors into the handlebars.
3. Place the handlebars over the seat assembly and hand tighten the four short 5 mm Dome
Head Screws with washer.
4. Using the 5 mm Allen Wrench tighten all four screws.
