E-1 Exercise Bike
STEP 4:
1. Connect the mid-sensor wire (33) to the computer wire (34). Attach the computer (32) onto the
computer support of the up-right post (21) using the screw (35)
2. Lock the handlebar post (29) onto the up-right post (21) by the square neck bolt (26), arc
washer (19) and nut (25),and then insert the pulse wire (28) into the back of the computer (32)
