25
Assembling Your Elliptical
E. Cut the corners of the bottom box and remove all packaging.
F. Place Ramp Base (2) in position to Main Base (1).
Step 2: Hardware Loss Prevention Sheet
A. The Main Base (1) has the Hardware Loss Prevention Sheet draped around
the Console Mast Support. The purpose of this paper is to act as a shield
to prevent bolts, washers and screws from falling into the Main Base
during assembly. Do not remove until assembly is complete. The paper
tears o quite easily when done and can be thrown away.
A
F
E
1
2
Hardware Loss
Prevention Sheet
Do Not Remove Until
Assembly is Complete
To Next Page
