34
G. Tear o Hardware Loss Prevention
Sheet.
H. Push Base Top Cover down into
position.
I. Attach Console Mast Cover (18) with
the four M4x10L screws removed in
step 4A and four more in the hard-
ware bag for a total of eight. Tools
needed: Phillips head screwdriver.
J. Inspect unit for excess packing
material and check that the roller
wheels are on the ramp rails.
Step 6: Console Attachment
(continued)
D. Tuck wires inside Console
(6) and Console Mast (4).
E. Slide Console (6) upwards
so hook on back of console
slides under holding plate
to lock into position.
F. Attach Console (6) by using
4 mm Allen
wrench and
the two
M5x10L
bolts and
M5 washers
(that were
pre-installed
on back of
console)
through
slots in
upper mast.
5mm Allen
Wrench w/
Phillips
PRE-INSTALLED
M4 x 10L Screw
(x4)
M4 x 10L Screw
(x4)
Console
Mast Cover
D
I
Slide
Lock
E
F
4mm Allen
Wrench
Assembling Your Elliptical
PRE-INSTALLED
M5 x 10L
(x2)
To Next Page
