# Name Specification NR # Name Specification NR
36 Fixed pin
φ5X1X12
2 83 Circuit wire and plug According to order 1
37 Pin spring
φ8.2Xφ0.8X15
1
38 Steel bushing
Outerφ16*Outerφ
14outer*φ10.1*12
4 85 Lifting motor 1/15Hp 1
39 Inner hexagonal wrench S6 1 86 Display 1
40 wrench
S13、S14、S15
1 87 Square magnet Line length 1000mm 1
41
φ32 spring sleeve
1 88 Hand pulse set Line length 380mm 2
42
φ38 spring sleeve
1 89 Trunk line 2 1200mm 1
43 Motor set 1 90 Trunk line 3 720mm 1
44 Semicircular caps 2 91 Controller 1
45 Decoration cover 1 92 transformer 1
46 93 Filter 63x51x38 1
47 Side slider 1038*50W 2 94 Current protecter 1
ASSEMBLY PARTS
Hardware contains
Part NO. Name Specification NR
I Production connection 1
II Plastic pedal 1
III Owner’s manual 1
VI Oil 1
VII Safety key 1
3、Cross pan-headed bolt ST4.2*15 headφ8
2
14. inner hexagonal
pan-headed bolt
M8*15 S6 8
VIII
16. inner hexagonal
pan-headed bolt
M8*50 teeth length10 S6 2
To Next Page
