25. inner hexagonal bolt M8x65 teeth length 20 8

28.Washer D8 12

7. Spring washer D8 4

Tools and nuts list：

Part NO. Name Specification NR

IV Cross-head wrench

S13，S14，S15

Inner hexagonal

wrench

S6 1

ASSEMBLY INSTRUCTIONS

1. Take out all the assembly parts from the treadmill package.

2．(1)Insert arc washer(7) into inner hexagonal pan-headed bolt(14), and fix them into the

separate holes with inner hexagonal wrench ;

(2) insert the washer(28) into inner hexagonal pan-headed bolt(16)，and fix them into the

separate holes with hexagonal wrench

(3) tighten left and right support, put decoration cover(45) onto the left and right support，

fix the cross pan-headed bolt(3) into the decoration cover(45).

3. (1)Insert arc washer(28) into inner hexagonal pan-headed bolt(14) , and fix them into the

separate holes with inner hexagonal wrench ;(2) Insert arc washer into inner hexagonal

pan-headed bolt(14),then fix the cross pan-headed (14) into left and right support, and

fasten them with Inner hexagonal wrench (S6).
