LifeSpan Super User Manual

PARTS LIST
# Name Specification NR # Name Specification NR
1 Cross pan-headed bolt ST4.2*12 10 48 Alloy cover ABS 1
2 Cross pan-headed bolt ST4.2*15 13 49 Upper cover PS 1
3 Cross pan-headed bolt
ST4.2*15 headφ8
4 50 Nether cover PS 1
4 Cross pan-headed bolt
ST4.8X30 headφ
10.5
4 51 Rubber cushion
φ30*16 φ5
6
5 Cross sunk-headed bolt ST3.5*20 2 52
Running board rubber
cushion
φouter29.5Xφ
inner10X6
8
6 Cross pan-headed bolt ST4.2*25 6 53 Nylon lace Length 100 9
7 Arc washer D8 6 54 Thick nylon lace 500*8*1.5mm 4
8 Cross pan-headed bolt
ST4.2*15 headφ6.5
4 55 Square cap
□50*25*2.0
2
9 Cross pan-headed bolt
M6x25 headφ<10
4 56 sleeve 28*12 2
10
Inner hexagonal
pan-headed bolt
M8*55 S6 teeth
length 20
2 57 Round cap 2
11
Cross sunk-headed
bolt
M5*12 teeth 5 58 Plastic running wheel
φ48*φ8*21
2
12
Cross sunk-headed
bolt
ST4.2*12 headφ6.2
5 59 Rubber running wheel
φ54*φ8*20
2
13
Cross sunk-headed
bolt
M6*35 teeth 8.8 8 60 Wax tube Length 200mm 1
14
Inner hexagonal
pan-headed bolt
M8*15 S6 20 61 Round cap 1
15
Inner hexagonal
pan-headed bolt
M8*30 teeth length
10 S6
2 62 sleeve
φ10X400
1
16
Inner hexagonal
pan-headed bolt
M8*50 teeth length
10 S6
4 63 Round sleeve
φ34.5X32.5X110
2
17
Inner hexagonal
pan-headed bolt
M8*50 teeth length
10 S6 8.8
2 64 Round caps
φ32
2
18
Inner hexagonal
pan-headed bolt
M10X50 S6 teeth
length 14 8.8
1 65 Plastic pedal 2
19
Inner hexagonal
pan-headed bolt
M10X95 S6 teeth
length 10 8.8
1 66 Gas spring 1
20
Inner hexagonal
pan-headed bolt
M8*38 teeth length 8
S6
2 67 Magnetic circle
φ25*φ15*12
2
21
Inner hexagonal
pan-headed bolt
M10*30 teeth 8.8 4 68
22 Inner hexagonal bolt M6*60 teeth S5 8.8 3 69 Rear roller 1
23 Cross pan-headed bolt
M6*22 teeth length
10 8.8
2 70 Running belt 2460*450*1.6 1
24 Inner hexagonal bolt
M8*75 S6 8.8 head
φ<16
1 71 Running board 1060*550*18 1
25
Inner hexagonal
pan-headed bolt
M8x65 teeth length
20
8
26 Flat washer D5 5 73 Current wire 6N-4 1
27 Flat washer D8 10 74 Owner’s manual 1
28 washer D8 24 75 Friction cushion 2
29 Flat washer D10 3 76 label 1
30 Nylon nut M10 1 77 Current switch 1
31 Nylon nut M6 11 78 Protecter 10A 250V 1
32 Spring washer D8 8 79 Connection wire 16#*170 1
33 Spring washer D10 5 80 Connection wire 16#*170 1
34 washer D5 inner teeth 1 81 Connection wire 16#*130 1
35 sleeve
Round steel：φ13X
φ8.2X40.2
2 82 Connection wire 16#*130 1

LifeSpan Super Specifications

General

Brand	LifeSpan
Model	Super
Category	Treadmill
Language	English
