Lifetime 60057 - Page 26

26
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
SEC
ADK (x4)
ADY (x4)
SEC
SEC
Insert a Truss Connector Bracket (BXW) into the slot in Truss Connector A as shown.
BXW
Place Truss Connector B (BXV)OVERTHE4RUSS#ONNECTOR"RACKETANDTHE4RUSS'UTTER#HANNELSASSHOWN)NSERT
four (4) #10 x 3/8” Pan-Head Screws (ADY) through a Truss Connector B as shown and lightly secure the Screws with
four (4) #10 Cap Nuts (ADK). Hand tighten only in this step.
3.3
3.4
3
