31
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
SEC
ADZ (x10)
SEC
SEC
Fold a Corner Wall Panel (AGL). Slide and snap it into place in the same manner as you did earlier. Fasten with the
required hardware. If necessary, place the Wood Block (AIW) underneath the Floor, directly below the tab to be
inserted, when snapping the tabs in place.
Snap a Wall Panel (AHD) into place along the right side of the shed. Ensure the top of the Wall Panel is even with
the Corner Wall Panel and the holes align. Insert 1/4” x 5/8” Pan-Head Screws (ADZ) through the holes of the Wall
Panels to fasten them together. Do not overtighten.
AHD
AGL
*AIW (x1)
Wood Block
4
4.5
4.6
To Next Page
