Lifetime 60057 - Page 32

32
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
SEC
SEC
Fold a Corner Wall Panel (AGL). Slide and snap it into place in the same manner as you did earlier. Fasten with the
required hardware. If necessary, place the Wood Block (AIW) underneath the Floor, directly below the tab to be
inserted, when snapping the tabs in place.
ADZX
SEC
Insert a Wall Support Channel (AFM) into the groove directly below the truss notch of each Wall Panel, including the
rear Wall Panels, as shown. Secure using the required hardware.
Truss Notch
ADZ
ADZ
ADZ
ADZ
AFM
AGL
*AIW (x1)
Wood Block
3
4.7
4.8
