TruScan 532 Single - Wavelength – Operators Manual Rev. No 02 Page 43 of 114
2. Straight Line Pattern
It can be selected or activated by touching the screen button and button will
submerge when it is activated. The final or pre selection will display in the pattern
display area.
Available parameter setting can be selected as follows:
- Spot size: 100-500μm
- Spacing: 0.5, 1.0, 1.5 and 2.0 Ф (not available in 500μm)
- Rotation: 0, 45, 90, and 135 degree
