MX4x4DVI-DL
User’s Manual
Page 37 / 43
Learn EDID from attached display device
The MATRIX SWITCHER can learn the EDID from the connected display device
and store it in one of user programmable memory.
All EDID is enumerated in the „Learn monitor EDID at output” list according to the
router’s outputs.
1. Select the desired display’s EDID from the list.
2. Choose a memory location from the to Memory list where the EDID will be
stored. Only memories 50...100 are available for user.
3. Press TAKE button. Now the EDID is stored in Matrix non volatile memory.
This procedure causes a status change and hence it is reported back to the
MATRIX CONTROL SOFTWARE within 2 seconds
