MMX8x4-HT series – User's Manual 114
Command and Response
ç
æ <out1_state>;<out2_state>;<…>;<out#_state>
Parameters
<out#_state> The responses contain one letter and a 1-byte long HEX code showing the current state of the
section.
INFO: The response depends on the number of the output ports. MMX8x4-HT400MC and MMX8x4-HT420M
models have 4 output ports, MMX8x8-HDMI-4K-A model has 8 output ports.
Example
ç
æ pr
INFO: Output 5 in MMX8x4-HT400MC and MMX8x4-HT420M models means the advanced analog audio output.
Command and Response
ç
æ <out1_set>;<out2_set>;<…>;<out#_set>
The response shows the settings of each output one by one.
Parameters
Parameter description Parameter values
<out#_set> Two-letter code of the
Autoselect settings
1
st
letter E: Autoselect is enabled
D: Autoselect is disabled
2
nd
letter F
P: Priority detect: always the highest priority active video
input will be selected.
L:
the output automatically.
Example
ç
æ
DP: the autoselect is Disabled on output 1, output 4, and output 5.
EP: the Autoselect is Enabled on output 2 (selected mode is Priority detect).
EF: the Autoselect is Enabled on output 3 (selected mode is First detect).
INFO: For more information see The Autoselect Feature section.
INFO: Output 5 in MMX8x4-HT400MC and MMX8x4-HT420M models means the advanced analog audio output.
Change the Autoselect Mode
Command and Response#autoselect
ç <out>:<out_set>)
æ
Parameters
See the previous section.
Example
ç
æ mO
The Autoselect mode is Enabled on Output 1 in First detect mode.
INFO: Output 5 in MMX8x4-HT400MC and MMX8x4-HT420M models means the advanced analog audio
output.
Command and Response
ç
æ <out1_list>;<out2_list>;<…>;<out#_list>
The response shows the priority of each output one after another. The priority number can be from 0 to 31; 0 is the
highest- and 30 is the lowest priority. 31 means that the port will be skipped from the priority list.
Parameters
<out_list> The input port priority order of the given output port: <in1>,<in2>,<…>,<in>
Example
ç
æ 0,1,2,3,4,5,6,7;0,1,2,3,4,5,6,7
contains eight priority numbers. The values show the priority order of the video input ports:
Output 1 Output 2 Output 3
I1 I2 I3 I4 I5 I6 I7 I8 I1 I2 I3 I4 I5 I6 I7 I8 I1 I2 I3 I4 I5 I6 I7 I8
7 6 5 4 3 2 1 0 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7
Output 3 Output 5
I1 I2 I3 I4 I5 I6 I7 I8 I1 I2 I3 I4 I5 I6 I7 I8
0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7
Input 8 has the highest priority, Input 7 has the lowest priority on O1. On O2 O3, O4 and O5 ports the setting is the
opposite.
ATTENTION!
match, the input port with the lowest port number will have the highest priority.
INFO: Output 5 in MMX8x4-HT400MC and -HT420M models means the advanced analog audio output.
