Lightware MMX8x8-HDMI-4K-A - Connecting Steps


4. Installation MMX8x4-HT series – User's Manual 33

CATx
Connect an HDBase-T
TM
-compatible transmitter or matrix output board to TPS input port.
MMX8x4-HT400MC model is not PoE-compliant, and MMX8x4-HT420M model is PoE compliant.
HDMI
Connect an HDMI source (e.g. PC) to the HDMI input port.
HDMI
Connect an HDMI sink (e.g projector) to the HDMI output port.
Audio

output port by an audio cable.
Mic
Please read the Installation Guide for Connecting a Microphone section before connecting the
microphone to the matrix. Not proper setting could damage the device.
Audio
Optionally for audio input: connect the audio source (e.g. media player) to the audio input port
by an audio cable.
USB

Controller software.
LAN
Optionally connect the UTP cable (straight or cross, both are supported) in order to control the

Relay
Optionally for relays: connect a controlled device(s) (e.g. a projection screen) to the relay port.*
IR

connector) to transmit infra signal.
GPIO

Power
Connect the power cord to the AC power socket to the matrix unit. It is recommended to power

*Only in MMX8x4-HT420M model.
Connecting Steps





