SMB/SB Installation and Maintenance Manual 140-11000 • July 2003 4-10
Flow Control Division
Limitorque Actuation Systems
Table 4.5 – SMB-000 Double Torque Switch Parts List
Piece Quantity320-2 Description 42
11Terminal Block
24Contact Block
34Contact Screw
44Finger Holder
54Finger
64Shunt
74Shunt Washer (
1
/4
”
O.D. x
3
/32
”
I.D. x
1
/32
”
Thick)
84Rivet
94Finger Spring Stud
10 4 Compression Spring
11 8 Spring Cup Washer
12 4 Cotter Pin (
3
/
64
”
x
1
/
4
”
)
13 4 Hex Head Machine Screw (#10-32 x
3
/8
”
)
14 4 Ring Tongue Connector 18" (#16 AWG Type TU Pigtail)
15 4 Shakeproof Lockwasher, Internal Teeth
16 1 Torque Switch Mounting Bracket
17 1 O-Ring
18 1 O-Ring
19 2 Socket Head Cap Screw (1/4-20 x
1
/2
”
Long)
20 1 Cam
21 1 Torsion Spring
22 1 Spring Mandrel
23 1 Dial
24 1 Shaft
25 2 Striker
26 1 Torque Limiting Plate
27 1 Striker Hub
28 1 Roll Pin (
1
/16
”
x
1
/2
”
)
29 1 #4 Swage Nut
30 2 Pan Head Screw (#8-32 x
5
/16
”
Long, Slotted)
31 2 Shakeproof Lockwasher, External Teeth
32 2 Flatwasher (
11
/
64
”
I.D. x
5
/
16
”
O.D. x .032” Thick)
33 1 Arm
34 1 Roller
35 1 Roller Pin
36 1 Groove Pin (
3
/32
”
diameter x
3
/32
”
)
37 1 Arc Barrier
38 1 Pan Head Screw #4-40 x
1
/4
”
39 1 Lockwasher, External Tooth
42 2 Spring Pin
43 1 Cam Insert
44 2 Bushing (For piece #16)
45 4 Washer
