Limitorque SMB Series User Manual

SMB/SB Installation and Maintenance Manual 140-11000 • July 20038-4
Flow Control Division
Limitorque Actuation Systems
Table 8.1 – SB-00 Parts List
Piece Quantity Description
1 1 Housing
21LS Compartment Cover
41Drive Sleeve
71Worm Gear
81Stem Nut
12 1 GL Drive Hypoid Gear
14 1 Clutch Key
22 1 Seal Retainer Plate
28 1 Clutch Ring
29 1 Worm Gear Spacer
42 1 Dowel Pin
43 1 Clutch Compression Spring
51 1 Bearing Shim
57 1 GLS Compartment Cover Gasket
63 1 Bearing Cup
64 1 Bearing Cone
65 1 Bearing Cup
66 1 Bearing Cone
78 1 Quad Ring
81 1 Ball Bearing
83 1 Torque Switch
87 1 Geared Limit Switch
96 1 Bevel Gear Housing
97 1 Bevel Pinion Cap
98 1 Bevel Gear Cartridge
99 1 Handwheel
100 1 Bevel Gear
101 1 Handwheel Bevel Pinion
102 1 Bearing Spacer
103 1 O-Ring Spacer
106 1 Bevel Pinion Cap Gasket
107 1 Bevel Gear Housing Gasket
108 1 Belleville Spring
109 1 Ball Bearing
110 1 Ball Bearing
111 1 Retaining Ring
113 1 Grease Fitting
115 1 O-Ring
116 1 O-Ring
117 1 O-Ring
118 1 Quad-Ring
119 1 Thrust Limiter Sleeve
120 1 Thrust Adapter Sleeve
121 1 Spring Housing Cover
122 1 Housing Cover Gasket
123 1 Spring Cartridge
124 1 Thrust Washer
125 1 Locking Nut
126 1 Socket Head Set Screw
130 6 Socket Head Cap Screw
131 6 Lockwasher
153 4 Hex Head Cap Screw
154 2 Socket Head Cap Screw
