Limitorque SMB Series - Figure 7.8 - SMB-00 Exploded View

Figure 7.8 – SMB-00 Exploded View
Slidewire
transmitter
Local dial
indicator
Top-mounted handwheel
Side-mounted handwheel
Motor operation
position
H.W. operation
position
