SMB/SB Installation and Maintenance Manual 140-11000 • July 20037-40
Flow Control Division
Limitorque Actuation Systems
Table 7.4 – SMB-5 and 5T Parts List (continued)
Piece Quantity Description
116 1 Torque Switch
117 1 Geared Limit Switch
125 1 Thrust Adapter Housing
126 1 Thrust Drive Sleeve
127 1 Stem Nut
128 1 Thrust Bearing Cartridge
129 1 Seal Retainer Plate
130 1 Drive Sleeve Locknut
131 2 Bearing Roller Assembly
132 1 Oil Seal
133 1 Grease Fitting
134 1 O-Ring
135 1 Gasket
136 1 Gasket
137 1 Threaded Flange
138 1 Sealing Washer
139 1 Bearing Cup
140 1 Bearing Cone
141 As required Bearing Shim
142 1 Bearing Spacer
215 1 Seal Retainer Sleeve
