Linak SMPS-T160

Connection diagram - Single run:
SMPS-T160
LA14 IC
TM
LA25 IC
TM
Bluetooth
receiver
RF receiver
HB40
DP
Signal cable
For more information on the flying leads, please see the I/O specifications in the user manual for the
chosen actuator
Fig. 1 : SMPST160+6UX0X0
Page 14 of 28
LA12 IC
TM
LA23 IC
TM
