Linak SMPS-T160

Cables:
The SMPS-T160 is designed with exchangeable cables.
Note:
• The signal and power cables must be ordered either seperately or together with the actuator.
Mains cables:
Plug types Article No. Material # Wires Size Colour Length
(mm)
Cable type
UL SML912065 PVC 3 18AWG Black 3200 Straight
Japan/CH
(Swiss)
SML912066 PVC 3 0.75mm
2
Black 3200 Straight
Australia SML912067 PVC 3 0.75mm
2
Black 3200 Straight
UK SML912099 PVC 3 0.75mm
2
Black 3200 Straight
EU SML912098 PVC 3 0.75mm
2
Black 3200 Straight/
angle
Actuator Plug
types
Article No. Material # Wires Size Colour Length
(mm)
Cable
type
LA14 IC/
LA25 IC
Minifit 1008w7200-300 PVC 8 18AWG Black 300 Straight
LA14 IC/
LA25 IC
Minifit 1008w7200-1500 PVC 8 18AWG Black 1500 Straight
LA12 IC Minifit 012913 PVC 8 22AWG Black 1500 Straight
LA23 IC Minifit 0237084 PVC 8 20/24AWG Black 1500 Straight
LA35 IC Minifit 0367136 PVC 4 18AWG Black 1500 Straight
Connection cable* between SMPS and actuator:
* Can be ordered seperately or mounted on:
LA12 IC
TM
, LA14 IC
TM
, LA23 IC
TM
, LA25 IC
TM
and LA35 IC
TM
.
Page 18 of 28
