Page 21 of 40
HB22RF2001 in general:
• For light/DC/USB and massage to function on the TD33, the TD3 must be configured. By default the TD33 will not operate
massage.
• Massage will turn off automatically 10 minutes after the last adjustment of the settings. This timing can be changed in the
TD3 configurator.
• Adjusting the bed or turning on/off the accessories is possible without any interruption.
• When pushing on the on/off button the massage motors will run in Continuous Mode. When pushing the Mode button the
massage mode will change.
• Turning on a single massage motor can also be done by pushing the right button for massage.
On/off (start/stop of the massage)
Mode (change between the different massage programs)
Controlling the backrest massage motor:
Keep the left button pressed to adjust the intensity down and the right button pressed to adjust the
intensity up. A short press on the right button turns on the massage motor at current intensity. The
massage will run in continues mode while being adjusted.
NOTE: The up/down intensity adjustment is reversed compared to the HB22RF2000
Controlling the leg rest massage motor
Keep the left button pressed to adjust the intensity down and the right button pressed to adjust the
intensity up. A short press on the right button turns on the massage motor at current intensity. The
massage will run in continues mode while being adjusted.
NOTE: The up/down intensity adjustment is reversed compared to the HB22RF2000
Store and recall settings
To store the current active massage settings, press the “S” button followed by either the “1” or “2”
button. To recall a previous stored setting, press the “1” or “2” button.
NOTE: By default the memory buttons only store the position of the TD3 back/leg
adjustment motors. Position and massage can be stored by activating this option in the
TD3 configurator.
Accessories for the TD3
Toggles on/off the light, DC or USB unit. Which function it controls is determined by the TD3
configured via the configurator.
Massage systems controlled by HB22RF2001
This HB is mainly used together with the TD33/CBH Advanced. With exception of LED, the TD33 by default is not
configured for massage, DC and/or USB accessories. The TD33 can be configured for these options in the configurator.
