80
336 804 3001.0704
Gear oil
Preferably SAE 80 W - 90 API GL5, also suitable is SAE 85 W
- 90 API GL4 (to DIN 51512).
Lubricating grease
Linde lithium-based heavy duty grease with EP additives
and MOS
2
.
Designation to DIN 51825 KPF 2N-20, (see Parts Catalogue
for Order No.)
Do not mix with greases having another base than lithium.
Battery grease
Non-acidic lubricating grease (terminal grease)
Chain spray
Linde chain spray (see Parts Catalogue for Order No.)
Brake fluid
DOT 3 brake fluid to SAE J 1703 (e.g. Ate type S) or DOT 4
to SAE J 1704 or FMVSS 116 (e.g. Ate type SL).
Hydraulic oil
Recommendation for regular duty:
Hydraulic oil ISO-L-HM 46 to ISO 6743-4 or HLP ISO VG 46
to DIN 51524 T.2 (factory filling), average continuous oil
temperature 40 °C to 60 °C.
Recommendation for heavy duty:
Hydraulic oil ISO-L-HM 68 to ISO 6743-4 or HLP ISO VG 68
to DIN 51524 T.2, average continuous oil temperature over 60
°C.
Recommendation for light duty at low ambient temperatures:
Hydraulic oil ISO-L-HM 32 to ISO 6743-4 or HLP ISO VG 32
to DIN 51524 T.2, average continuous oil temperature under
40 °C.
Recommendation for strongly varying operating condition:
All the above applications can be covered with an hydraulic oil
ISO-L-HV 46 to ISO 6743-4 or HVLP ISO VG 46 to DIN 51524
T.3.
Such hydraulic oils have a high viscosity index (multigrade
oils).
Bio hydraulic oil
Biologically fast-degradable pressure fluid
Aral Forbex SE 46
ATTENTION
Do not mix bio-oils with mineral oils. Other fluids
from other manufacturers cannot be
recommanded.
NOTE
The above oil recommendations are only guidelines.
If case of doubt we recommend contacting your author-
ized Linde distributor.
Recommendations of representatives of the oil industry
should also be checked with your authorized truck deal-
er.
Only the above-mentioned
oils are approved by the
manufacturer. Costly damage can result if other hydraulic
oils are used or mixed.
Lubricant recommendations
Vaseline
