Turning mechanism, gear oil injection port
Hydraulic oil filler port
A
B
C
Table of recommended fuels and oils
Designation Model no. Amount added Position used
Antifriction hydraulic oil L-HM46 0.21L Hydraulics
Moly lithium grease no.
3
Grease (contains MoS2) 110 g Gearbox
Moly lithium grease no.
3
Grease (contains MoS2) As appropriate
Turning mecha-
nism
Maintenance
5
Inspection and Maintenance
65Operating Instructions - 1131 801 1601 EN - 12/2021 - 04
